The K-Tor Power Box is a 20 Watt pedal generator with an universal international power socket. Plug in your wall charger and charge your portable electronics at the same rate as plugging in a wall outlet. You can charge an external battery to power larger devices like laptops or appliances. Bundled with Powerstream a 12 volt charger to charge 12 volt batteries. Battery Charger Specifications Model PST-3P10-12V (3PA1015, 3P10-A1015) Name 12 Volt charger for lead acid, sealed lead acid, etc. Rated input voltage 90-264 VAC, 50/60 Hz Battery size 12 volt nominal SLA, VRLA, Gel, AGM, or flooded Input Frequency 50-60 Hz 6 cells 12 volts nominal Charging current 0.8 amps or 800 mA Charging algorithm Constant current/constant voltage/float Stage 1 constant current 800 mA ± 100 mA For Stage 1 to start battery voltage must be above 4V Stage 2 constant voltage 14.75 volts ± 0.25 volts Stage 3 float charge 13.75 ±0.25 volts "Charged" light turns on and float charge starts when the charge current is below 0.20 amps ±0.05 amps when the battery charge voltage is above 14 volts. Output power 14W maximum Output voltage 14.75 volts maximum Output Sturdy 20AWG wires, rated to 80°C Alligator clips Weight 150 grams, 0.15 kg, 0.33 pounds, 5 oz. Cooling Natural convection, no fan Efficiency >75% Size 75 x 51 x 28 mm, 3 x 2 x 1 inches Environment -10°C to +40°C operating, -40°C to +70°C storage Temperature rise <40°C rise on case under any line voltage and maximum rated load Vibration, Impact 5mm, 50Hz, 600 Seconds, 1 meter drop 3 times Protections Reverse Polarity, Short circuit protection Safety UL, cUL, CE marked, designed to ED60950, EN55022B MTBF 30,000 hours by MIL-STD calculation HiPot, ESD Hi-Pot 3000 V, 1 minute ESD 8000V LED Indications Power on, but no battery connected Green Charging Red Finishing Charge Green Flashing Charged/Float Charging Green (may be dim Green) Reverse polarity or short circuit Red and Green Flashing Alternately
